Product overview
Extended length bulk containers are built for parts that do not fit a standard 48 inch pallet box. They are 48 inches wide and 57 to 70 inches long, with side drop doors for access. Spring latches make assembly and knock-down quick. Non-sequential folding keeps the walls from bowing when you collapse them.
Construction and features
- 57-1/4, 64-1/2 and 70 in lengths
- Rated to 2,000 lbs
- Side drop doors
- Spring latches for fast assembly and knock-down
- Non-sequential folding prevents wall bowing
- Colour: black
Extended length container sizes
Scroll sideways to see all specification columns. Capacity is based on an evenly distributed load.
| Part number | Outside L × W × H (in) | Inside L × W × H (in) | Capacity (lbs) | Volume (cu ft) | Return ratio | Drop doors |
|---|---|---|---|---|---|---|
| JBBS57483420 | 57-3/10 × 48 × 34 | 53-1/2 × 44-1/2 × 26-3/5 | 2,000 | 36.7 | 2.5:1 | 2 (long side) |
| JBBS57484420 | 57-1/4 × 48 × 44 | – | 2,000 | – | – | 2 (long side) |
| JBBS64483420 | 64-1/2 × 48 × 34 | 60-4/5 × 44-1/2 × 26-3/5 | 2,000 | 41.7 | 2.5:1 | 2 (long side) |
| JBBS64484420 | 64-1/2 × 48 × 44 | – | 2,000 | – | – | 2 (long side) |
| JBBS70483420 | 70 × 48 × 34 | 66-3/10 × 44-1/2 × 26-3/5 | 2,000 | 45.4 | 2.5:1 | 2 (long side) |
Ordering notes
Tell us the part length, load weight and quantity. Use the inquiry form below and include your delivery location.
